Threaded Bolts for Toggle Clamps
Replacement threaded spindle bolts for compatible toggle clamps and workholding fixtures. Choose the thread size, length and material that match your application and clamp compatibility.
Product Specifications
- RT1135 (M5X1.32): Competitor Clamp# 305USS-201USS; Competitor Accessory # 201943-M; RMT Clamp # RT1022-RT1020; Material: 304 Stainless Steel; Contains: Threaded Bolt & 2 Nuts
- RT1151 (#8-32X.78): Competitor Clamp# 601; Competitor Accessory # 105203; RMT Clamp # RT1040; Material: High Quality Carbon Steel; Contains: Threaded Bolt
- RT1157 (M6X1.74): Competitor Clamp# 602MMSS-202USS; Competitor Accessory # 202943-M; RMT Clamp # RT1011-RT1018; Material: 304 Stainless Steel; Contains: Threaded Bolt & 1 Nut
- RT1158 (M6X1.74): Competitor Clamp# 602-MM; Competitor Accessory # 205203-M; RMT Clamp # RT1033; Material: High Quality Carbon Steel; Contains: Threaded Bolt & 2 Nuts
- RT1159 (1/4-20X2.15): Competitor Clamp# 602; Competitor Accessory # 205203; RMT Clamp # RT1036; Material: High Quality Carbon Steel; Contains: Threaded Bolt & 1 Nut
- RT1160 (M4X.89): Competitor Clamp# 205-USS; Competitor Accessory # 205943-M; RMT Clamp # RT1023; Material: 304 Stainless Steel; Contains: Threaded Bolt & 2 Nuts
- RT1161 (M8X2.17): Competitor Clamp# 603-M; Competitor Accessory # 207203-M; RMT Clamp # RT1031; Material: High Quality Carbon Steel; Contains: Threaded Bolt & 1 Nut
- RT1162 (M10X3.00): Competitor Clamp# 210-S; Competitor Accessory # 237943-M; RMT Clamp # RT1063; Material: 304 Stainless Steel; Contains: Threaded Bolt & 2 Nuts
- RT1163 (M8X2.77): Competitor Clamp# 604MMSS-207-USS-225-USS; Competitor Accessory # 207943-M; RMT Clamp # RT1009-RT1021; Material: 304 Stainless Steel; Contains: Threaded Bolt & 1 Nut
- RT1164 (5/16-18X2.17): Competitor Clamp# 604-MM; Competitor Accessory # 207943; RMT Clamp # RT1034; Material: High Quality Carbon Steel; Contains: Threaded Bolt & 1 Nut
- RT1165 (M10X2.22): Competitor Clamp# 608M-624MM-630M; Competitor Accessory # 210203-M; RMT Clamp # RT1027-RT1030-RT1026; Material: High Quality Carbon Steel; Contains: Threaded Bolt & 1 Nut
- RT1168 (5/16-18X2.72): Competitor Clamp# 603-604-604-MM-605-607-609; Competitor Accessory # 207203; RMT Clamp # RT1025-RT1032-RT1034-RT1035-RT1037-RT1038; Material: High Quality Carbon Steel; Contains: Threaded Bolt & 1 Nut
- RT1169 (5/16-18X2.18): Competitor Clamp# 604-SS; Competitor Accessory # 207943; RMT Clamp # RT1008; Material: 304 Stainless Steel; Contains: Threaded Bolt & 1 Nut
- RT1170 (3/8-16X2.75): Competitor Clamp# 624-610; Competitor Accessory # 210203; RMT Clamp # RT1028-RT1029; Material: High Quality Carbon Steel; Contains: Threaded Bolt & 1 Nut
- RT1172 (5/8-11X5.35): Competitor Clamp# 267-U; Competitor Accessory # 267203-M; RMT Clamp # RT1056; Material: High Quality Carbon Steel; Contains: Threaded Bolt & 2 Nuts
- RT1174 (1/4-20X1.50): Competitor Clamp# 602-SS; Competitor Accessory # 202943; RMT Clamp # RT1010; Material: 304 Stainless Steel; Contains: Threaded Bolt & 1 Nut
- RT1198 (5/16-18X1.25): Competitor Clamp# None; Competitor Accessory # None; RMT Clamp # RT1038-1.25; Material: High Quality Carbon Steel; Contains: Threaded Bolt & 1 Nut
- RT1199 (5/16-18X2.2): Competitor Clamp# None; Competitor Accessory # None; RMT Clamp # RT1038-OG; Material: High Quality Carbon Steel; Contains: Threaded Bolt & 1 Nut
- RT1414 (M4X.89): Competitor Clamp# None; Competitor Accessory # None; RMT Clamp #None; Material: High Quality Carbon Steel; Contains: Threaded Bolt & 2 Nuts
Specifications & Dimensions
| SKU | Thread × Length | Length (in) | Width (in) | Height (in) | Compatible RMT Clamp | Material |
|---|---|---|---|---|---|---|
| RT1135 | M5X1.32 | 1.32 | 0.34 | 0.14 | RT1022-RT1020 | 304 Stainless Steel |
| RT1151 | #8-32X.78 | 0.78 | 0.24 | 0.17 | RT1040 | High Quality Carbon Steel |
| RT1157 | M6X1.74 | 1.74 | 0.39 | 0.16 | RT1011-RT1018 | 304 Stainless Steel |
| RT1158 | M6X1.74 | 1.74 | 0.39 | 0.16 | RT1033 | High Quality Carbon Steel |
| RT1159 | 1/4-20X2.15 | 2.15 | 0.55 | 0.21 | RT1036 | High Quality Carbon Steel |
| RT1160 | M4X.89 | 0.89 | 0.15 | 0.27 | RT1023 | 304 Stainless Steel |
| RT1161 | M8X2.17 | 2.17 | 0.54 | 0.21 | RT1031 | High Quality Carbon Steel |
| RT1162 | M10X3.00 | 3 | 0.71 | 0.25 | RT1063 | High Quality Carbon Steel |
| RT1163 | M8X2.77 | 2.77 | ,47 | 0.2 | RT1009-RT1021 | 304 Stainless Steel |
| RT1164 | 5/16-18X2.17 | 2.17 | 0.54 | 0.21 | RT1034 | High Quality Carbon Steel |
| RT1165 | M10X2.22 | 2.22 | 0.65 | 0.23 | RT1027-RT1030-RT1026 | High Quality Carbon Steel |
| RT1168 | 5/16-18X2.72 | 2.72 | 0.46 | 0.27 | RT1025-RT1032-RT1034-RT1035-RT1037-RT1038 | High Quality Carbon Steel |
| RT1169 | 5/16-18X2.18 | 2.22 | 0.47 | 0.2 | RT1008 | 304 Stainless Steel |
| RT1170 | 3/8-16X2.75 | 2.75 | 0.54 | 0.23 | RT1028-RT1029 | High Quality Carbon Steel |
| RT1172 | 5/8-11X5.35 | 5.35 | 0.89 | 0.38 | RT1056 | High Quality Carbon Steel |
| RT1174 | 1/4-20X1.50 | 1.5 | 0.38 | 0.16 | RT1010 | 304 Stainless Steel |
| RT1198 | 5/16-18X1.25 | 1.45 | 0.46 | 0.2 | RT1038-1.25 | High Quality Carbon Steel |
| RT1199 | 5/16-18X2.2 | 0.46 | 0.31 | 0.46 | RT1038-OG | High Quality Carbon Steel |
| RT1414 | M4X.89 | 0.89 | 0.15 | 0.27 | None | High Quality Carbon Steel |
Features & Benefits
- Replacement threaded bolt spindle accessories for compatible toggle clamps
- Available in multiple thread sizes, lengths, and materials; see individual SKU specifications
Applications
- Workpiece Holding: Used with compatible toggle clamps to help secure workpieces during machining, assembly, and fabrication operations.
- Adjustable Clamping Applications: Provides adjustable contact positioning to accommodate different workpiece sizes, thicknesses, and configurations.
- Jigs & Fixtures: Ideal for use in custom jigs, fixtures, and workholding setups requiring consistent clamping contact.
- Manufacturing & Assembly: Suitable for production environments, welding fixtures, woodworking, and general industrial applications.
- Versatile Toggle Clamp Compatibility: Designed for use with compatible horizontal, vertical, and push/pull toggle clamps in a wide range of workholding applications.
